CHANGING THE PAPER SIZE OF THE CASSETTE
When you want to use a different size of paper in the cassette, do the following.
NOTE: You need a #2 Philips
screwdriver for this procedure.
Upper Cassette
1. Remove the upper cassette.
CAUTION:
To avoid dropping the cassette hold it
by the front and side while pulling it out.
2. Push the white lever [A] in the direction shown in the diagram below.
3. Change the position of the bracket [B] in accordance with the paper size
which you wish to install.
[A]
[B]
CHANGING THE PAPER SIZE OF THE CASSETTE LOOKING AFTER THE MACHINE
