Runco VX-6000d Installation/Operation Manual 51
PRE
L
IMINAR
Y
4.1
Using the On-Screen
Menus To display the Main Menu, press the MENU button on the remote control (Figure 2-5) or
DHD Controller front panel (Figure 2-3).
To select a menu item, use the and buttons on the remote control or DHD Controller
front panel to highlight it. Then, to confirm your selection, press ENTER on the remote
control or DHD Controller front panel.
The VX-6000d OSD menus are arranged hierarchically, as shown in Figure 4-1.
Depending on the selected input source and signal characteristics, some menu options
may not be available.
Figure 4-1. VX-6000d OSD Menu Structure
4. Operation
Input Source
Composite
S-Video 1
S-Video 2
Component
HD1
HD2
SCART
HDMI 1
HDMI 2
Aspect Ratio
16:9
4:3
Letterbox
VirtualWide
Cinema
Virtual Cinema
Native
Brightness
Contrast
Color
Tint
Sharpness
Noise Filter
Input Position
Left/Right
Up/Down
Width
Height
Overscan
Overscan Mode
(Zoom/Crop)
Phase
(RGB/Component/SCART signals
only)
Tracking
(RGB/Component/SCART signals
only)
Memory
Presets
Recall ISF Night
Recall ISF Day
Recall/Save Custom
Recall/Save THX
Reset Custom or THX to Factory
Default
Information
Signal
System
Field Service
Manufacturing
Calibration
Display Color
Gain -100, -99... 0 ... 99, 100
(Red, Green, Blue)
Offset
Gamma -30, -29... 0 ... 29, 30
Lamp
Power
(180W or 220W)
Color Temp.
Simple
(5500K, 6500K, 7500K or
9300K)
SatCo (BrilliantColor™) On/Off
RVR 0 (fully open) or 1
Input Image
Brightness
-50, -49 ... 0 ... 49, 50
Contrast
Color
Tint
Sharpness
Input Color
Gain -32, -31... 0 ... 31, 32
(HD 1, HD 2 and
Component inputs only)
Offset
Chroma Delay
0, 1, 2 ... 7
(S-Video 1, S-Video 2 and
Composite inputs only)
Noise Filter 0, 1, 2 ... 63
Save ISF Night
Back / Confirm
Save ISF Day
Copy/Paste
Copy Settings
Paste Settings
Output Shift
Left/Right
-50, -49 ... 0 ... 49, 50
Up/Down
Width
-50, -49, 48 ... 0
Height
Splash Configure
Owner Name
ISF Calibrated
ISF Other
Splash Timer 5, 6, 7 ... 15 ... 59, 60
Splash Enable On/Off
OSD Position Hor. / Ver. 0, 1, 2 ... 100
Note: Default settings appear in bold type.
