Page 60: Pre l iminar y
44
Runco VX-6000d Installation/Operation Manual
PRE
L
IMINAR
Y
Figure 3-20. Vertical and Horizontal Lens Shift Adjustments
3.9
Adjusting the Picture
Orientation
By default, the VX-6000d is configured for a “floor/front” installation, in which the projector
is installed upright and in front of the screen. If it is installed behind the screen and/or
mounted on a ceiling, you must change the picture orientation. To do this:
1.
On the DHD Controller remote control or front panel, press MENU.
2.
Select Service from the Main Menu and enter the Service Menu passcode.
3.
Select Display Device from the Service Menu.
4.
Select Configure from the Display Device menu, then select Installation.
5.
Select Orientation, then choose Floor/Rear, Ceiling/Front or Ceiling/Rear, to match
the installation method.
Vertical
Horizontal
You must enter a passcode to access the Service menu for the first
time after turning on the system.
Note
