Figure 3-5 . horizontal lens shift (example only), 5. horizontal lens shift (example only), Figure 3-5 – Runco CINEWIDE VX-6000D User Manual
Page 39: Pre l iminar y
Runco VX-6000d Installation/Operation Manual
23
PRE
L
IMINAR
Y
Figure 3-5. Horizontal Lens Shift (Example Only)
0%
Screen Center
100% Width Lens Shift
(1.0 x W)
50% Width Lens Shift
(0.5 x W)
Screen Width (W)
Note: This is a general example of lens shift. Lenses vary in their shift capabilities. No particular
lens or projector is used in this example.
