Installation
Runco VX-6000d Installation/Operation Manual 19
PRE
L
IMINAR
Y
3.2
Quick Setup Table 3-1 gives a quick overview of the VX-6000d installation process. The sections
following this one provide detailed instructions.
Installation should be performed by a qualified custom video
installation specialist.
Table 3-1. Installation Overview
Step Procedure
For Details, Refer to
page...
1 Choose a location for the projector 20
2
If installing a VX-6000d/CineWide or
VX-6000d/CineWide with AutoScope: Install AutoScope
lens motor or fixed CineWide base plate 26
3 Mount the projector 31
4 Connect the DHD Controller to the projector 31
5 Connect signal sources to the DHD Controller 33
6 Connect external controller to RS-232 port (optional) 38
7
Connect 12-volt trigger outputs to AutoScope lens motor
and/or other equipment (optional) 39
8
Connect projector, DHD Controller and lens motor (if
present) to AC power and power up 42
9
Primary Lens adjustments: projected image size (zoom),
position (shift) and focus 22, 43
10
For rear-screen and/or ceiling-mount installations, select
the proper picture orientation 44
11 Install CineWide anamorphic lens (optional) 45
12
CineWide lens adjustments: position, pitch (angle),
geometry and focus 47
13
Projector calibration: adjust the following for each input;
save settings when finished:
• Aspect ratio
• Brightness
• Contrast
• Color level
• Tint
• Input position 53 through 67
Note
