Installation
Runco VX-6000d Installation/Operation Manual 31
PRE
L
IMINAR
Y
3.5
Mounting the
VX-6000d There are several methods for mounting the projector. Depending on your chosen
installation, one method may be more suitable than another.
Floor Mounting (Upright) In typical front and rear screen installations, the projector can be mounted to a secure and
level surface such as a table or cart. Carts are useful when moving a projector during a
presentation or from site to site. If possible, lock the wheels when it’s in position to prevent
it from being moved during a presentation.
Ceiling Mounting
(Inverted) For fixed installations, and for those that want the projector out of sight or have a limited
space for projector and audience, you can invert the VX-6000d and suspend it from the
ceiling using a specially-designed ceiling mount fixture.
The projector can also be inverted and placed in an enclosure above and behind the
viewing area. Install four feet on the inside bottom surface of the enclosure on which the
projector can rest. A variety of materials can be used for this purpose (for example, rubber
crutch tips or turntable feet).
Adjusting the Projection
Angle If the VX-6000d is ceiling-mounted and the screen is significantly lower than the projector,
you can tilt the projector at a slight angle by adjusting the ceiling mount.
If you do this, you may need to shift the image using the OSD controls, to compensate.
For detailed instructions, refer to Using the On-Screen Menus on page 51.
3.6
Connections to the
VX-6000d and DHD
Controller Proceed as follows to connect the DHD Controller to the VX-6000d, your video sources,
external controller(s) – if present – and AC power.
When connecting your equipment:
• Turn off all equipment before making any connections.
• Use the correct signal cables for each source.
• Route all cables through the cable opening at the bottom rear of the projector (see
Figure 2-1).
• Ensure that the cables are securely connected. Tighten the thumbscrews on
connectors that have them.
Connecting the DHD
Controller to the VX-6000d The VX-6000d is designed to receive only video input signals directly from the companion
DHD Controller/Scaler/Processor. Connect all signal sources to the appropriate inputs on
the rear panel of the DHD Controller. The signal from the DHD Controller is then output to
the VX-6000d projector through an HDMI cable.
Use only the Runco-approved ceiling mount kit (part number
956-0074-00) designed for your projector. Install the mount kit
according to the instructions provided with it.
Note
You CANNOT connect signal sources directly to the VX-6000d.
They MUST be routed through the DHD Controller for proper
operation.
Note
