Publication 1771-6.5.132 - June 2000
Creating and Running the Example Application Program 6-3
The Select Processor Type window will open.
3. Enter the following information and click on OK.
In this field Select or Enter
Processor Name DNET_PLC
Platform ControlNet
Processor (Select your processor type)
Series (Select your processor’s series)
Revision (Enter revision letter)
Driver
(Select a Driver)
(1)
(1) You can use the Who Active button to select your communications driver. This is described in the
“Downloading” sections of this chapter.
Processor Node
(Enter the Processor Node)
(1)
TIP
Ignore any prompts or warnings you receive
about specifying ControlNet project files. That is
not necessary for this example.
