23

3. Configuring the Printer for the

Network with the Operation Panel

Configuring the Printer for the Network
with the Operation Panel

After installing the optional network
interface board, configure it for the
network using the printer's operation
panel.

Note

❒ If you want to print from your

Macintosh computer, the optional
RICOH-SCRIPT2 Type305 is re-
quired.

The following table shows the opera-
tion panel settings and their default
settings. These are included in the
”System Menu”.

A

Press

{{{{

Menu

}}}}.

B

Press

{{{{U

U

U

U}}}}{{{{T

T

T

T}}}} until the following

message appears.

j

System Menu l

C

Press

{{{{

Enter

}}}}.

D

Select the protocol you want to
use. You can select one of items
on the table below.

•

' means that this protocol is ac-
tive.

• Blank cell means that this proto-

col is not active.

•

means that this protocol is

not supported.

*1

TCP/IP

*2

NetWare

*3

EtherTalk

*4

NetBEUI: NetBEUI appears on the

panel display, but it is not support-

ed.

Items

Default

32 IP Address

011.022.033.044

33 Subnet Mask

000.000.000.000

34 Gateway Add

(Gateway Address)

000.000.000.000

35 Access CTL.

(Access Control Address)

000.000.000.000

36 Access Mask

(Access Control Mask)

000.000.000.000

37 Net Boot

(Network Boot)

None

38 Frame NW

(Frame type NetWare)

Auto Select

39 Active PTL.

(Active Protocol)

All Active

Menu item on the

panel display

Active Protocol

TCP

*1

NW

*2

ET

*3

NB

*4

All Active
(Default Setting)

'

'

'

None

TCP/IP Only

'

NetWare Only

'

TCP & NetWare

'

'

EtherTalk Only

'

TCP & EtherTalk

'

'

NetW & EtherTalk

'

'

TCP & NW & EtherTk

'

'

'

NetBEUI Only

TCP & NetBEUI

'

NetW & NetBEUI

'

TCP & NW & NB

'

'

ETalk & NetBEUI

'

TCP & ETK & NB

'

'

NW & ETK & NB

'

'
