4.5.5 External Dimensions of the Converter Board M3T-F160-100NSD
Figure 4.12 shows external dimensions and a sample foot pattern of the converter board for a 100-pin 0.5mm pitch LQFP
M3T-F160-100NSD (not included).
Figure 4.12 External dimensions and a sample foot pattern of the M3T-F160-100NSD
4.5.6 External Dimensions of the Converter Board M3T-F160-128NRD
Figure 4.13 shows external dimensions and a sample foot pattern of the converter board for a 128-pin 0.5mm pitch LQFP
M3T-F160-128NRD (not included).
