Page 106
106
Chapter 8 Features Using MIDI and Setting Examples
Combining with an External
MIDI Sequencer
Importing Sequence Data from an
External MIDI Device to the TD-6’s
Internal Sequencer
You can load data created on another sequencer from the
MIDI IN connector and record the data on the TD-6’s
sequencer, then use the data as a song. The backing part (Parts
1–4), percussion part, and drum kit part can be imported
simultaneously.
When TD-6’s instruments are changed from an external MIDI
device, the change is not recorded by the TD-6’s sequencer.
Use the TD-6 to make each part’s instrument settings.
For more on external MIDI device operations, refer to the
owner’s manuals for the devices you are using.
1.
Use a MIDI cable to connect the MIDI IN
connector of the TD-6 to the MIDI OUT
connector of the external MIDI device.
fig.08-002.e
2.
Match the MIDI channel to be used for
transmitting data from the external MIDI device
and the MIDI channel that the TD-6 will use for
receiving the data.
3.
Set “CH10Priorty (Channel 10 Priority)” as
needed when recording drum and percussion
performances.
(SETUP/MIDI COMMON/CH10Priorty; p. 99)
4.
Set “Sync Mode” to “EXT” in order to
synchronize the TD-6 to the external sequencer.
(SETUP/MIDI COMMON/Sync Mode)
5.
Select one of the TD-6’s new User songs (p. 84).
You can select a new User song by holding down [SHIFT]
and pressing [STOP
] while in the Song screen.
New User songs are indicated by “
” in the display.
6.
Make the settings for the TD-6’s parts.
Specify the part instruments and percussion sets, volume
levels, etc.
7.
Press [REC
], then make the recording
Time Sig:
Set the beat (time signature) to comply with
that of the loaded data.
Rec Mode:
Set this to “REPLACE.”
8.
Start playback of the external MIDI device.
The TD-6 automatically begins recording.
9.
When you have finished recording, stop the
recording of the external MIDI device.
The TD-6 stops recording automatically.
Recording Your Performance to an
External Sequencer
This makes the settings that allow performances of the pads to
be recorded by an external MIDI sequencer.
1.
Use a MIDI cable to connect the TD-6 and MIDI
sequencer MIDI connectors as shown in the
following figure.
fig.08-003.e
2.
Set Local Control to “OFF.”
(SETUP/MIDI COMMON/LocalControl; p. 98)
3.
Match the MIDI channel to be used for
transmitting data from the TD-6 and the MIDI
channel that the external MIDI sequencer is to
use for receiving the data.
MIDI OUT
MIDI IN
TD-6
External MIDI Sequencer
TD-6
OUT
OUT
IN
IN
External MIDI Sequencer
