Ricoh BIZWORKS 106 - Manual (Page 221)

ix
GENERAL
DESCRIPTION
Type 2
The following describes the Type 2 machine.
Automatic document feeder
(ADF)
Holds up to 10 sheets of paper for automatic
feeding. Place originals face down.
Platen cover
Lift this cover to access the exposure
glass when you want to scan a page
from a book, magazine, or any other
original that cannot be fed using the
ADF.
Document guides
Slide the left guide to fit
the size of the paper you are feeding.
Original guide
Guides the original
correctly into the machine.
Make sure your original
fits under this guide.
Top unit
Upper
paper tray
Exposure glass
Operation panel
Output tray
extension
Top release lever
Output tray
Power switch
Upper tray
extension
Extend to support
originals.
Document output tray
Scanned documents are delivered here.
Second printer
(Additional Printer) port
Computer port
Small size
paper feed
access panel
Power socket
SIMM cover
Scanner lock
