88
Appendix B: WLAN Application Gateway 2246
5 Enter the default login name (admin) and the default password (admin).
The NetLink OAI System menu appears. See Figure 20 on page 88 .
Figure 20 NetLink OAI System menu
The NetLink OAI System menu of the Administration Console displays the factory-default
name of the WLAN Application Gateway 2246 to which the serial port is connected.
Configuring the WLAN Application Gateway 2246
The NetLink OAI System menu is the main menu of the Administration Console. Use this screen
to configure the WLAN Application Gateway 2246.
Note: The login name and password are case-sensitive.
Note: If the WLAN Application Gateway 2246 is a MOG6xx model, the TFTP Server
Download Configuration option appears on the NetLink OAI System menu.
