NTI VEEMUX AUDIO/VIDEO MATRIX SWITCH VIA CAT5
19
SS_00- Disable Auto Status Mode
Command:
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6
‘S’
(0x53)
‘S’
(0x53)
Space
(0x20)
‘0’
(0x30)
‘0’
(0x30) (0x0D)
Response:
Byte 1 Byte 2
‘
∗’
(0x2A) (0x0D)
This command disables auto status mode.
SX- Examine connections
Command:
Byte 1 Byte 2 Byte 3
‘S’
(0x53)
‘X’
(0x58) (0x0D)
Response:
Multiple lines, one line for each output:
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8 Byte 9
‘p’
(0x70)
‘c’
(0x63)
Space
(0x20)
Output – 1st digit
(0x30 … 0x32)
Output – 2nd digit
(0x30 … 0x39)
‘:’
(0x3A)
Input – 1st digit
(0x30 … 0x32)
Input – 2nd digit
(0x30 … 0x39) (0x0D)
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8 Byte 9
‘p’
(0x70)
‘c’
(0x63)
Space
(0x20)
Output – 1st digit
(0x30 … 0x32)
Output – 2nd digit
(0x30 … 0x39)
‘:’
(0x3A)
Input – 1st digit
(0x30 … 0x32)
Input – 2nd digit
(0x30 … 0x39) (0x0D)
Last line:
Byte 1 Byte 2
‘
∗’
(0x2A) (0x0D)
Terminate telnet session
Command:
Byte 1 Byte 2 Byte 3
‘X’
(0x58)
‘X’
(0x58) (0x0D)
Response:
Byte 1 Byte 2
‘
∗’
(0x2A) (0x0D)
The unit will respond with
‘ * ’ and close the connection, terminating the telnet session. The unit is then available for future
connections.
