Chapter 1
Generating Functions with the NI 5401
1-2
www.natinst.com
Connecting Signals
Figure 1-1 shows the front panels for the NI 5401 for the PXI and PCI
buses. The front panel contains three types of connectors: BNC, SMB, and
50-pin very high-density SCSI (VHDSCSI). The main waveform is
generated through the connector labeled ARB.
Figure 1-1. NI 5401 I/O Connectors
ARB OUT
SYNC OUT
EXT TRIG
PLL REF
LOCK ACCESS
PXI
PCI
SYNC
PLL IN
ARB
P
A
TTERN OUT
