Chapter 2

Function Generator Operation

©

National Instruments Corporation

2-11

NI 5401 User Manual

Pre-Attenuation Offset

The NI 5401 hardware supports a DC offset of up to ±2.5 V before the
attenuation chain. Unless the 10 dB attenuator is switched in, which occurs
when the amplitude is less then 3.16 V

pk-pk

, the waveform maximum plus

the offset must not exceed ±5 V into 50

. If it does, the waveform is

clipped. Refer to Figure 2-8 for a diagram showing the location of the
10 dB attenuator.

NI-FGEN automatically calculates the pre-attenuation offset value based
on the DC offset and amplitude values, so the allowable DC offset range is
dependent on the amplitude. For example, if you have an amplitude of
1 V

pk-pk

, the maximum DC offset you can apply is 0.25 V, which

corresponds to a pre-attenuation offset of 2.5 V.

Note

You can change the DC Offset at any time during waveform generation. Refer to

your software documentation for additional information.

Phase-Locked Loops and Board Synchronization

Figure 2-11 illustrates the block diagram for the NI 5401 for PCI PLL
circuit. Figure 2-12 illustrates the block diagram for the NI 5401 for PXI
PLL circuit. The PLL consists of a voltage-controlled crystal oscillator
(VCXO) with a tuning range of ±100 ppm. This VCXO generates the main
clock of 80 MHz.

The PLL can lock to a reference clock source from the external connector,
from a RTSI Osc line on the RTSI bus (NI 5401 for PCI), or from a
10 MHz Osc line on the PXI backplane bus (for NI 5401 for PXI). The PLL
can also be tuned internally using a calibration DAC (CalDAC). National
Instruments accurately performs this tuning during manufacturing. Refer to
the

RTSI/PXI Trigger Lines

section later in this manual for additional

information on using the RTSI and 10 MHz Osc lines.

The reference and VCXO clock are compared by a phase comparator
running at 1 MHz. The loop filters the error signal and sends it to the control
pin of the VCXO to complete the loop.
