Pitco Solstice and Solstice Supreme High Efficiency Gas Fryers
L22‐345 R1
84
Optional Basket Lift
The basket lift is a self contained unit that requires a 120V, 208V, or 240V supply. With most fryer
configurations, the power is supplied from the entrance box at the back of the fryer, but some configurations
require power direct from a wall outlet.
When supply voltage is applied to the basket lift assembly, it goes through a voltage selector switch to a multi tap
24V, 80VA transformer. The transformer supplies 24 VAC to the driver board at connection J54.
NOTE: When power is supplied to basket lift assembly, the baskets lifts to the up position.
When a timer is activated, it sends a 24 VDC signal to pin #1 (24 VDC+) at connector J51 on the driver board.
The driver board generates a 24 VDC output at J53 to the basket lift motor, lowering the basket.
NOTE: For the purpose of testing, jumping pins #1 and #2 at connection J5 on the driver board will
simulate a 24 VDC signal from the controller, lowering the basket.
