Panasonic AG-HPX500E - Manual (Page 98)

98
Preparing for Audio Input
C
h
ap
te
r 5 P
re
p
ar
at
io
n
Preparing for Audio Input
Take the following steps to prepare the camera for
connecting audio input devices.
When Using the Front
Microphone
The AJ-MC200G microphone kit (optional) includes a
microphone that can be mounted on the camera.
1
Open the microphone holder.
2
Mount the microphone and tighten the
clamping screw.
3
Connect the microphone cable to the
MIC IN jack on the camera.
4
Set the AUDIO IN switch to [FRONT]
depending on the audio channel to be
recorded.
When the microphone connecting cable is connected to
the FRONT2 jack and the AUDIO IN switch CH1 is set to
FRONT2 and switch CH2 is set to FRONT, sound from
the microphone sound is input to both channels.
MIC IN Jack
Microphone holder
Viewfinder
Clamping Screw
AUDIO IN Switch
