130
Setup menu list
C
h
ap
te
r 7 M
en
u O
p
er
at
io
n
s
OPTION MENU screen
This screen is displayed when you press the front MENU button after displaying the shooting status by pressing
and holding down the DISP/MODE CHK button. Use this screen to confirm the connection status during nonlinear
editing.
Item Description of settings
1394 STATUS
/
The 1394 status sub-screen is displayed.
●
FORMAT: format of the signal being input or output
● RATE: transfer rate of the signal being input or output
● 60/50: system of the signal being input or output
● CH: channel number being input or output
● SPEED: transfer speed of the signal being input or output
● STATUS: status of the signal being input or output via the IEEE 1394 digital interface
● VIDEO: status of the video signal being input or output
● AUDIO: status of the audio signal being input or output
1394 CONFIG
/
The 1394 expanded menu is displayed.
●
DFLT: Normally use the menu as displayed.
1-255
