17
C
h
ap
te
r 2 P
ar
ts a
n
d t
h
eir F
u
n
ct
io
n
s
7 LINE/MIC/+48V (line input/mic input/mic
input + 48V) selector switch
Used to select the audio signal input from the
REAR1/REAR2 connectors.
LINE: Audio signal line-input from the audio
device is input.
MIC: Audio signal from a self-powered (active)
microphone is input. (The main unit
does not supply power to the remote
microphone).
+ 48V: Audio signal from a passive microphone
is input. (The unit supplies power to the
remote microphone).
Power is supplied when R.MIC POWER in the
screen is set to ON.
8 FRONT AUDIO LEVEL (audio recording
level adjustment) control
• This control adjusts the recording level of Audio
Channels 1 and 2.
• Level adjustment is possible when the AUDIO
SELECT switch is set to MAN.
• Use the menu options FRONT VR CH1 and
FRONT VR CH2 in the
screen to select the input connector this control
will be used for.
9 Viewfinder connector
For details, refer to [Mounting the Viewfinder]
(page 88).
