148
Dimensions and specifications
C
h
ap
te
r 1
0 S
p
ec
ifi
ca
tio
n
s
Other Input/Output
TC IN: BNC × 1, 0.5 V p-p to 8 V p-p, 10 k Ω
TC OUT: BNC × 1, low impedance, 2.0 V p-p ± 0.5 V p-p
IEEE1394: 6 pins, digital input/output (compliant with IEEE 1394)
DC IN: XLR × 1, 4 pins, DC 12 V (11.0 V to 17.0 V)
DC OUT: 4 pins, DC 12 V (11.0 V to 17.0 V), max. 1.5 A
REMOTE: 10 pins
LENS: 12 pins
EVF: 20 pins
USB2.0 (DEVICE): Type-B, 4 pins (compliant with USB ver. 2.0)
LCD Monitor
LCD monitor: 3.5-inch LCD color monitor, 210,000 pixels (4:3)
Accessories
Accessories: • 1.5-inch viewfinder (4:3 CRT, NTSC/PAL switchable)
• Shoulder strap
• Ferrite core (2)
• Front Audio Level control knob (page 101)
• Control knob mounting screw
• Component video cable
• PIN-BNC conversion plugs (3)
• CD-ROM
• Operating Instructions
