111
Setting of Clip Meta Data
C
h
ap
te
r 6 M
an
ip
u
la
tin
g C
lip
s w
ith T
h
u
m
b
n
ail
s
■ Example of recording (DVCPRO50) a clip on
one P2 card:
REC start (recording start) REC/PAUSE (recording pause)
Recording duration = Approx. 15 min.
Clip 1
COUNT value
= 0001
Clip 2
COUNT value
= 0002
10 min. 5 min.
■ Example of recording a clip on two P2
cards:
REC start (recording start) REC/PAUSE (recording pause)
Clip 1
COUNT value
= 0001
Clip 2
COUNT value
= 0002
1st card 2nd card
If the clip thumbnails are displayed as shown in the
example above or their properties are indicated using
a P2 device, the thumbnail and COUNT value of clip 1
will be displayed.
Clear the uploaded metadata
Select META DATA →INITIALIZE, and press the SET
button. Select “YES” when the confirmation screen is
displayed.
Displaying loaded metadata
Select METADATA → PROPERTY and press the SET
button to display the metadata recorded in this unit.
