95
Mounting and Adjusting the Lens
C
h
ap
te
r 5 P
re
p
ar
at
io
n
Setting Chromatic Aberration
Compensation (CAC)
The CAC function of the camera corrects the
registration error caused by the slight chromatic
aberration that the lens cannot compensate for. This
minimizes color bleeding into the surrounding image
areas.
Lenses compatible with the CAC function whose CAC
data is registered in the camera will automatically start
CAC operation.
CAC data for the following four lenses have been
registered in the camera as default values.
Camera indication
Model numbers of
compatible lenses
KJ16EX7.7B IRSD PS12
KJ16ex7.7B IRSD PS12
KJ16ex7.7B KRSD PS12
KJ21EX7.6B IRSD PS12 KJ21ex7.6B IRSD PS12
KJ10EX4.5B IRSD PS12 KJ10ex4.5B IRSD PS12
XA17X7.6BERM-M58B
XA17x7.6BERM-M58B
XA17x7.6BRM-M58B
• One of the lens model number appearing in the menu
represents the lens group.
• The CAC function in this camera operates in horizontal
direction only.
• The CAC function does not operate at +18 dB.
• The CAC function may not operate normally in macro
shooting.
• After the release of this camera, visit our Web site at
the address given below for details on new lenses
compatible with this function and any changes in this
function.
https://eww.pavc.panasonic.co.jp/pro-av/
Checking CAC Operating Status
Press the DISP/MODE CHK button when no menu is
open.
• CAC is running if “CAC” appears in the upper right
corner of the screen.
CAC
Checking CAC data number and CAC
data during operation
1
Open the setting menu LENS SETUP
screen.
For details on menu operation, refer to [Using
the menus] (page 116).
2
Turn the JOG dial button to select CAC
PROPERTY and select YES to open the
CAC PROPERTY screen.
• The CAC property list appears.
PUSH MENU TO RETURN
SHADING(USER)
SHADING SELECT
LENS SETUP
DEFAULT
CAC PROPERTY
CAC CARD READ
CAC FILE DELETE
CAC FILE INIT
IRIS ADJUST OFF
YES
■ CAC Property
PUSH MENU TO RETURN
FILE NO : 1
ACTIVE CAC FILE NO : 1
CAC PROPERTY
MAKER : CANON
TYPE :
KJ16EX7.7B IRSD PS12
VERSION : 1.00-00-0.00
DATA ERROR
PLEASE READ CAC CARD
3
4
2
1
1
Current CAC data number
2
Data number of CAC you wish to check
Turn the JOG dial to select.
3
CAC data specified by 2
4
Error messages
The file cannot be used if an error message
appears. Initialize the CAC data or reload the
CAC file from an SD card.
For details, see [Initializing CAC File] (page 97) or
[Loading CAC File from an SD Card] (page 96).
