Chapter 4. Trunks and Lines Section 300-Installation
4-20 DBS Manual - Revised April 2000 DBS-2.3/9.2-300
Installation
The following procedures provide step-by-step instructions for installing the
T1 Interface. The procedure that you should use depends on the type of
system you have and the number of T1s you are installing.
If you are installing ... Use this procedure...
A T1 in a single cabinet “Installing a T1 in a Single Cabi-
net” (page 4-21)
One T1 in a double cabinet, with the
T1 located in the master “Installing a T1 in a Single Cabi-
net” (page 4-21)
One T1 in a double cabinets, with the
T1 located in the slave “Installing a T1 in a Double Cabi-
net with the T1 in the Slave”
(page 4-27)
T1s in both the master and slave “Installing a T1 in a Double Cabi-
net with T1s in the Master and
Slave” (page 4-27)
