Chapter 7. Specifications Section 300-Installation
7-14 DBS Manual - Revised April 2000 DBS-2.3/9.2-300
Communication Parameters
Table 7-12. Voice path from KTELs to DBS
Table 7-13. Data communications ports
Channel Speed
Overall communications path 256 kbps
D-channel data 16 kbps
B-channel data 64 kbps
Port Parameters
SMDR Interface RS232-C
Baud rate 300, 1200, 4800 or 9600 kbps
Parity Even, odd, or none
Stop bit length 1, 1.5, or 2
Data bit length 5, 6, 7, or 8
Maintenance (RAI card) Baud rate 300 (RAI-A) or 300 or 1200 (RAI-B)
Stop bit length 1
Data bit length 8
Parity None
