Section 300-Installation Chapter 3. Cabinet Installation
DBS-2.3/9.2-300 DBS Manual - Revised April 2000 3-7
• Before installing the CPC card, determine if the DBS will be used as a
KSU or PBX. To use it as a PBX, cut Strap S1 on the CPC. Cutting this
strap allows use of pooled trunks as opposed to line appearances.
Figure 3-6. CPC Strap S1
• Install cards only in their dedicated slots. The slot type is marked on the
cabinet directly above each slot.
C PC -AIIor
C PC -B
S1
C utS1 forPooled Trunks (PBX O peration)
D o N otC utS1 forLine A ppearances (KS U O peration)
