Section 300-Installation Chapter 5. Peripheral Equipment
DBS-2.3/9.2-300 DBS Manual - Revised April 2000 5-7
Figure 5-3. RAI connection
R A I-A (VB -43706): 300 bps
or
R A I-B (VB -43707): 300 or 1200 bps
SC C -B C ard
(VB -43421)
H ooks
O FF
O N
SW 4
J1
1 2 4 8 16
7dB m
R A I-B C ard
Sets attenuation level.
The attenuation is the
sum
of the "O N " settings.
Leave J1 C losed
(300 B PS/1200
B PS M ode)
