Chapter 6. Double-Cabinet Systems Section 300-Installation
6-12 DBS Manual - Revised April 2000 DBS-2.3/9.2-300
5. Set SW1 on the CBL-M card according to the following table.
Table 6-2. CBL-M switch settings
System Combinations Switch Settings
Master Slave 1 2 3 4 5 6 7 8
DBS40 DBS40 ON ON ON ON ON ON OFF ON
DBS72 DBS40 ON OFF ON ON ON ON OFF OFF
DBS72 DBS72 ON OFF ON OFF ON OFF ON OFF
DBS96 DBS40 OFF ON OFF ON ON OFF OFF OFF
DBS96 DBS72 OFF ON OFF ON ON OFF OFF OFF
DBS96 DBS96 OFF ON OFF ON ON OFF OFF OFF
