Appendix A. EX 1.0 Feature Update Section 300-Installation
Page A-4 DBS Manual - Revised April 2000 DBS-2.3/9.2-300
SMDR Modifications
SMDR reports contain several additional call types and other parameters due to CPC-EX
support of T1 Networking and ISDN calls.
ISDN Support
CPC-EX supports ISDN-PRI (Integrated Services Digital Network -- Primary Rate
Interface). The program address for Trunk Circuit Type (FF2 (trunk #)# 21#) has been
modified to allow for ISDN. Programming addresses have also been added in CPC-EX to
support ISDN. (See the ISDN Reference Manual for complete instructions.)
Modification to T1 Signaling Types
To allow easier programming of E&M trunks, CPC-EX uses “Wink Start” (not “Immediate
Start”) as the default for T1 Incoming and Outgoing Signal Types.
Installation Notes
CPC-EX Installation
Use normal installation procedures to install the CPC-EX. The following illustration shows
an installed CPC-EX:
