Section 300-Installation Appendix B. CPC-AII/B 8.0 Feature Update
DBS-2.3/9.2-300 DBS Manual - Revised April 2000 Page B-13
EM/24 - Key Arrangement
44-Series phones only
CPC-AII/B Version 8.0, CPC-S/M Version 2.0, or CPC-EX Version 1.0 only
Description
The keys on the enhanced EM/24 unit (VB-44310) are arranged differently
from the VB-43310 model. The enhanced EM/24 unit has 2 columns x 12
rows of keys (not 3 columns x 8 rows as in the previous version). This
affects the following:
• FF-Keys. The FF-keys on the EM/24 are numbered bottom-to-top, left
column first.
The newer arrangement for the EM/24 keys is shown in Figure 15.
Figure B-15.EM/24 Unit (VB-44310) keys
FF12 FF24
FF11 FF23
FF10 FF22
FF9 FF21
FF8 FF20
FF7 FF19
FF6 FF18
FF5 FF17
FF4 FF16
FF3 FF15
FF2 FF14
FF1 FF13
