Table 4-11. T1 and analog trunk assignments, DBS 96
Trunk Assignments for Double-Cabinet Systems
• When T1 is used in a double-cabinet system, the number of T1 channels
that can be assigned in each cabinet depends on the master/slave
designation.
The following table shows the maximum number of T1 channels that can
be assigned in two-cabinet systems.
Table 4-12. Maximum T1 assignments for two-cabinet systems
• Two-cabinet systems use the same trunk numbering scheme as single-
cabinet systems. Analog trunks are numbered from “1” upward; T1 trunk
channels are numbered downward from the highest channel used.
Trunk
Number
24-Channel T1
Fractional T1
using 16
Channels
Fractional T1
using 8 Channels
1
Analog trunk 1
Analog trunk 1
Analog trunk 1
↓
↓
↓
↓
8
Analog trunk 8
Analog trunk 8
Analog trunk 8
9
T1 channel 24
Analog trunk 9
Analog trunk 9
↓
↓
↓
↓
16
T1 channel 17
Analog trunk 16
Analog trunk 16
17
T1 channel 16
T1 channel 16
Analog trunk 17
↓
↓
↓
↓
24
T1 channel 9
T1 channel 9
Analog trunk 24
25
T1 channel 8
T1 channel 8
T1 channel 8
↓
↓
↓
↓
32
T1 channel 1
T1 channel 1
T1 channel 1
System Size
Master
Slave
DBS 40 + DBS 40
8 analog trunks
16 T1 trunks
DBS 72 + DBS 72
16 analog trunks
24 T1 trunks
DBS 96 + DBS 40
24 T1 trunks
8 analog trunks
16 T1 trunks
DBS 96 + DBS 72
24 T1 trunks
8 analog trunks
24 T1 trunks
DBS 96 + DBS 96
24 T1 trunks
8 analog trunks
24 T1 trunks
8 analog trunks
