Upgrading Firmware 44
FS6300 NMS User Manual 2 • Discovering Your Network
Forcing Discovery for Selected Cards
Though the cards have the updated information saved, the NMS will not display the changes until the cards
have been re-discovered. To re-discover specific cards and not the entire subnet, see
“Re-Discovering Cards
Manually” on page 38.
Upgrading Firmware
The FS6300 NMS supports the following Patton models:
The rack cards must have the following minimum firmware version installed in order to operate properly:
To update the firmware for a rack card:
1. Click on Tools > Firmware Upgrade at the top of the screen.
Figure 30. Tools > Firmware Upgrade
Supported Rack Cards Supported CPE Devices
6511 3201
3196RC 3088
3096RC 3086
2616RC 1082 (C/D/I/F)
Card Minimum Firmware Version Required
6511 6511RC-1.2.9.img
3196RC 3196RC-1.3.9.img
3096RC 3096RC-1.5.16.img
2616RC 2616RC-1.3.9.img
