Viewing the iDSL Map Layer
125
FS6300 NMS User Manual
7 • Configuring the 3196RC Card
Viewing the iDSL Map Layer
Click on Display iDSL Map Layer to show a map of all the iDSL ports on the card. Right-click on a port in
the map to configure its link. See
on page 110 for more details.
Figure 109. 3196RC iDSL Port Map
