B. Standards Compliance for SNMP Traps
B-4
February 2001
8784-A2-GB20-30
The tests that affect the enterpriseTestStart, enterpriseTestStop, and the
variable-bindings are different for each particular interface. Diagnostic tests are
only supported on the physical T1 network and user data port interfaces. The
specific tests and variable-bindings are described in the following table:
Interface
enterpriseTestStart/Stop
Variable-Bindings
Possible Cause
DSL Network
T
ifIndex (RFC 1573)
T
ifAdminStatus (RFC 1573)
T
ifOperStatus (RFC 1573)
T
ifType (RFC 1573)
T
ifTestType (RFC 1573)
The following objects control tests
in SNMP-managed devices:
– noTest – Stops the test in
progress.
– testLoopLLB – Initiates a Local
Loopback.
– testLoopRLB – Initiates a
Remote Loopback.
– testSendMon511 – Initiates a
Send and Monitor 511 test.
– testSendLLBUp – Initiates an
LLB Up message to the
remote unit.
– testSendLLBDown – Initiates
an LLB Down message to the
remote unit.
T
enterpriseTest Start – Any
one of the following tests is
active on the interface:
– Line Loopback
– Repeater Loopback
– Remote Line Loopback
– Send and Monitor 511
T
enterpriseTest Stop – No
tests currently running on
the interface.
DSX-1
T
ifIndex (RFC 1573)
T
ifAdminStatus (RFC 1573)
T
ifOperStatus (RFC 1573)
T
ifTestType (RFC 1573)
The following objects control tests
in SNMP-managed devices:
– noTest – Stops the test in
progress.
– testLoopExternalDTE
T
enterpriseTest Start – Any
one of the following tests is
active on the interface:
– Data Terminal
Loopback
– Repeater Loopback
– testLoop RLB – initiates
a Repeater Loopback
– testLoop DTLB –
initiates a DSX-1 DTE
Loopback
T
enterpriseTest Stop – No
tests currently running on
the interface.
