6. Messages and Troubleshooting
6-2 February 2001 8784-A2-GB20-30
Configuring SNMP Traps
An SNMP trap can be automatically sent out through the EOC or the Management
port to the SNMP manager when the termination unit detects conditions set by the
user. These traps enable the SNMP manager to gauge the state of the network.
Refer to
Appendix B, Standards Compliance for SNMP Traps , for details of SNMP
traps supported by the unit.
To configure the unit for SNMP traps, use the SNMP Traps Options screen to:
T Enable SNMP traps.
T Set the number of SNMP managers that receive SNMP traps from the unit.
T Enter an IP address and network destination for each SNMP manager
specified.
T Select the type of SNMP traps to be sent from the unit.
To configure SNMP Traps, follow this menu selection sequence:
Main Menu
→
Configuration
→
Current Configuration
→
Management and Communication
→
SNMP Traps
Refer to Table A-8, SNMP Trap Options, in Appendix A, Configuration Options, to
configure SNMP traps.
main/config/management/trap Hotwire
Slot: 4 Model: 8784
SNMP TRAPS OPTIONS
SNMP Traps: Enable Number of Trap Managers: 5
NMS 1 IP Address: 135.014.040.001 Clear Destination: IMC
NMS 2 IP Address: 135.014.003.027 Clear Destination: IMC
NMS 3 IP Address: 135.014.001.008 Clear Destination: IMC
NMS 4 IP Address: 135.014.002.024 Clear Destination: IMC
NMS 5 IP Address: 204.128.146.035 Clear Destination: IMC
General Traps: Both
Enterprise Specific Traps: Enable
Link Traps: Both
Link Traps Interfaces: Network
-------------------------------------------------------------------------------
Ctrl-a to access these functions, ESC for previous menu MainMenu Exit
Save
