2. Using the Asynchronous Terminal Interface
8784-A2-GB20-30 February 2001 2-5
Screen Work Areas
There are two user work areas:
T Screen area – This is the area above the dotted line that provides the menu
path, menus, and input fields.
The menu path appears as the first line on the screen. In this manual, the
menu path is presented as a menu selection sequence:
Main Menu
→
Configuration
→
Current Configuration
→
Network
T Function key and message area – This is the area below the dotted line that
lists function keys specific to the screen, field value choices, and system
messages.
main/config/network Hotwire
Slot: 4 Model: 8784
Port: 2
NETWORK INTERFACE OPTIONS
Margin Threshold: –3db
Excessive Error Rate Threshold: 1E–5
AutoRate Disable
DSL Line rate 1552
Circuit Identifier: Clear
--------------------------------------------------------------------------------
Ctrl-a to access these functions, ESC for previous menu MainMenu Exit
Save
Select: 1E–4, 1E–5, 1E–6, 1E–7, 1E–8, 1E–9 LOS at Net, Pt n
Input
Fields
Menu
Path
Field Value
Choices System
Messages
Function
Keys
