A. Configuration Options
A-4 February 2001 8784-A2-GB20-30
DSX-1 Interface Options
For DSX-1 Interface Options, refer to Table A-2, DSX-1 Interface Options . To
access the DSX-1 Interface Options screen, follow this menu selection sequence:
Main Menu
→
Configuration
→
Current Configuration
→
DSX-1
main/config/DSX-1 Hotwire
Slot 4 Model: 8784
Port 2
DSX-1 INTERFACE OPTIONS
Port Status: Enable
Line Framing: ESF
Line Coding: B8ZS
Line Equalization: 0-133
Excessive Error Rate Threshold: 1E-4
Send (AIS) on Network Failure: Enable
Send All Ones on DSX-1 Failure: Enable
Primary Clock Source: DSX-1
--------------------------------------------------------------------------------
Ctrl-a to access these functions, ESC for previous menu MainMenu Exit
Save
