4-CH MPEG-4 Digital Video Recorder 47
8.1.4 AP Functions
Image Display
NO. Button Function Description
1
Image View Tab Click the tab to select the view you want..
2
/ / /
Expand All Views
To see all views in the image display area if you have
many views and do not want to switch each view by
clicking the blue tab described above, click to choose a
proper split view (1-cut / 4-cut / 9-cut / 16-cut) which
best suits your needs.
The selected view will be indicated with a red frame
around it.
3 Full Screen
Click to view the images in the full screen mode.
To exit the full screen mode, press “Esc” key on the
keyboard.
f Close
Click to close the current image display view.
If the last image display view is closed, you will be
logged out automatically.
g Close All Views
Click to close all the image display view and disconnect
nected device(s). from the con
