Identifying the media path – Lexmark C520 User Manual
Page 64
Identifying the media path
64
Clearing jams
•
Make sure the media size in the sources matches the size setting selected from the operator panel menus.
•
Make sure all cables that connect to the printer are correctly attached. See the Setup sheet for more information.
Identifying the media path
The following illustration shows the path that media travels through the printer. The path varies depending on the input
source (tray 1 or tray 2) and if a duplex (two-sided) print job is being sent.
When a jam occurs, the printer issues a message indicating the region of the jam. Only the three-digit jam prefix numbers
are given in the following illustration. For the same three-digit jam numbers and a description of the jam location, see the
table starting on page 66.
203
203
202
201
200
Each blue line
represents a 200
area.
250
230
242
241
