Lexmark 1361760 - Manual

Q: Cartridge will not print?
A: If the cartridge does not print after
refilling, rest the print nozzles on a
wet tissue. This will draw ink through
the nozzles. Leave for 10 minutes
and try printing again.
Use a blade or sharp knife to remove the cap
from the top of the cartridge. Insert the blade
into the sealing joint between the cap and
the body and carefully pry it off . Note: Be
very careful not to break the cap.
Cap
Phone Support
1300 730 018
E
a
s
re
f
ls
y
il P
a
ra
ti
re
p
o
n
- Put on the gloves supplied
- Cover your work area in newspaper
in case of accidental spillage.
- Read these instructions thoroughly
- Remove the cartridge from your
printer (only do this when
ready to refill.)
NB: Ink stains so we would
recommend you wear old
clothes or an apron when
refilling.
Preparation:
Kit Contents:
3 x ink bottles (blue, red, yellow)
1 x plastic gloves
1 x absorbent pad
4 x stickers
1
S
e
p
t
O
n
e
e
p
S
t
T
h
re
e
3
2
S
e
p
t
T
w
o
S
te
p
F
o
u
r
e
S
t
p
F
iv
e
e
p
i
S
t
S
x
5
6
4
T
b
o
i
ro
u
le
s
h
o
t
n
g
?
Q: Prints with streaks through text or
image?
A: This could mean that the print nozzles
are blocked, therefore preventing ink to
flow freely. To correct this problem use
the printers cleaning routine. If this does
not work, rest the print nozzles on a wet
tissue. This will draw ink through the
nozzles. Leave for 10 minutes and try
printing again.
Q: Ink stains on hands and clothes?
A: To clean your hands, first wash
thoroughly in soap and warm water.
If the stains persist, try using bathroom
cleaner. It may take several washes to
remove the ink. There is no real solution
to ink stained clothes. However if you
are using a dy cleaner, you can tell them
the ink is based upon water soluble dye
with ethylene glycol added.
S
te
p
S
e
v
e
n
7
Matchstick
Replace the cap on top of the cartridge
(see step 2) and secure with two of the
stickers provided. Alternatively you can use
super glue or a hot melt glue gun to stick
the cap back on.
S
e
p
i
h
t
t
E
g
Using the absorbent pad, clean any
foreign materials or excess ink. If
the nozzles on the bottom of the cartridge
leak, blot with tissue until leaking stops.
Lexmark
1361760
Printer Compatibility:
Lexmark PM-100,PM-3200,5000,5700,7000,
7200,OPTRA COLOR 40,40n,45,45n,45n
SOLARIS,Z11,Z31
Instructions
www.easyrefills.com.au
Kit Code: K30CLR
l
G
e
n
e
ra
I
n
fo
rm
a
ti
o
n
Easyrefills manufacturers all refill kits at it’s
Queensland headquarters. Importing the
finest quality American made inks that are
in most cases better than or equal to
original manufacturers specifications. Each
kit has a shelf life of two years and is
covered by a 100% guarantee.
Cartridge Stats:
Colour: Tri-colour (Red, Blue, Yellow)
Ink Capacity: 5 ml per chamber
Weight when full: 68 grams
Number of refills per kit:
8 refills per kit
AUSTRALIAN MADE
www.easyrefills.com.au
E
s
t
a
y
re
fi
lls
k
i
Copyright 2004 Easyrefills. All names and numbers used are
registered trademarks of their respective owners.
Insert the plug provided into the refilling
hole. Gently squeeze the sides of the
cartridge while resealing the hole. An air
tight seal must be formed. Cover the hole
and plug with one of the stickers provided.
8
Using the drill tool provided, drill a hole
at point ‘A’. Once you have penetrated the
first layer of plastic you will meet a sponge.
Stop drilling when you feel this sponge.
Insert the refill needle into the hole containing
the ink you wish to refill. Angle the needle
toward the ink outlet hole at the bottom of
the cartridge and push down as far as
possible.
S-l-o-w-l-y and gently squeeze the ink refill
bottle to force ink into the cartridge. This
must be done with very little pressure, pulling
the needle upward as you go. Each chamber
takes approximately 5ml of ink.
Repeat Steps 4-5 for each colour you wish
to refill. Using the absorbent pad clean any
foreign materials or excess ink from the
top of the cartridge. Install the cartridge into your printer and
run the head cleaning utility (see printer
manual). For best results wait 20 minutes
before you resume printing.
Place the cartridge on the absorbent pad
provided. If a few drops of ink leak onto
the pad do not worry, this is normal.
Identify which colour is under each refilling
hole by using the end of a matchstick or
toothpick as shown above. Insert the match-
stick into the hole as far as possible,
remove and check for colouring on stick.
View From Top
Body
Print Nozzles
Sealing joint
Cap
Body
Sticker #1
