Use the To
17 USB port Connect the printer to a computer using a USB cable.
Warning—Potential Damage: Do not touch the USB port except when plugging in or
removing a USB cable or installation cable.
18 LINE port Connect the printer to an active telephone line through a standard wall jack (RJ
‑11), DSL
filter, or VoIP adapter, or any other adapter that allows you to access the phone line to
send and receive faxes.
19 Power supply with port Connect the printer to the power cord.
20 Ethernet port Connect your printer to a computer, a local network, an external DSL, or a cable modem.
21 Duplex unit • Print on both sides of a sheet of paper.
• Clear paper jams.
22 Printhead access area Install the printhead.
Note: The carrier moves to the printhead access area when no printhead is installed in
the printer.
23 Jam clearance cover Access and clear paper jams.
24 Ink cartridge access area Install, replace, or remove ink cartridges.
25 Scanner unit • Access the ink cartridges and printhead.
• Clear paper jams.
About your printer 12
