Lexmark 24XX-100 - Manual (Page 157)

Parts Catalog 7-17
24xx
Asm-
Index Part
Number
Description
5 - 1 12G3814 Support, ASF Cut Sheet W/ Guides (2480, 2490)
1 12G3908 Support, ASF Cut Sheet W/ Guides (2481, 2491)
2 95F6886 Roller, ASF Upper Feed (2480, 2490)
2 95F6896 Roller, ASF Upper Feed (2481, 2491)
3 95F6887 Roller, ASF Lower Feed (2480, 2490)
3 95F6897 Roller, ASF Lower Feed (2481, 2491)
4 95F6885 Roller, ASF Pick-up Left and Right (2480, 2490)
4 1333275 Roller, ASF Pick-up Left and Right (2481, 2491)
5 12G3911 Hopper, ASF Right (2480, 2490)
5 12G3893 Hopper, ASF Right (2481, 2491)
6 12G3912 Support, ASF Paper Right
7 12G3914 Support, ASF Paper Center (2481, 2491)
8 12G3915 Support, ASF Paper Left
9 12G3916 Hopper, ASF Left
10 12G3933 Lever, ASF Paper Load
11 12G3934 Link, ASF Paper Load
12 12G3918 Cover, ASF Left
13 95F6892 ASF Gears and Bushings, Parts Packet
14 95F6893 ASF Springs, Parts Packet
15 95F6894 ASF Screws, Parts Packet
16 12G3944 Frame, ASF Side Left
