MERLIN LEGEND Communications System Release 5.0
System Manager’s Guide
555-650-118
Issue 1
June 1997
System Components
Page 3-17 Telephones
3
MLX-20L telephones cannot be wall-mounted.
When used as a QCC, some restrictions apply. The line buttons are not
programmable, and the console cannot have an MFM. Later in this chapter,
‘‘Queued Call Consoles’’ on page 3-30 provides more information about QCCs.
Figure 3–5. MLX-20L Telephone
Handset
Fixed-Display
Buttons (4)
Display Screen
Button Labeling Cards
Line Buttons (20)
Message Light
Dialpad
Volume Control
Fixed-Feature Buttons (8)
User Cards and Tray
v
v
Volume
Feature
HFAI
Mute
Speaker
Transfer
Conf
Drop
Hold
ABC DEF
GHI JKL MNO
PQRS TUV WXYZ
OPER
1 2 3
4 5 6
7 8 9
0 # *
MLX-20L
Home
Menu
More
Inspct
Unlabeled Display
Buttons (10)
