Managing the System
Page 6-8 Introduction to System Programming
6
on the console or next to Enter ( on the PC).You can use the Inspect feature
to view, verify, or check the entries you save: press the Inspct fixed display button
on the console or press
h on the PC. After you have finished inspecting the
entries, you can return to the previous screen by pressing the unlabeled display
button next to
Exit or by pressing
!
on the PC. See System Programming for
more information about the Inspect feature.
Figure 6–3 shows a data entry screen with the first (of two) required extension
numbers needed to assign analog voice and data.
Figure 6–3. Data Entry Screen
System Programming Menu 6
Figure 6–4 shows the two screens that make up the System Programming menu.
This is the main menu of system features and options. You reach the System
Programming menu by selecting
Sys Program from the system’s main menu.
Table 6–2 lists the System Programming menu options and describes each one.
Figure 6–4. System Programming Menu Screens
The system programming hierarchy, included in Appendix B of System
Programming, details the sequence of screens you work with when you select the
system programming options.
Data Voice/Data >
Selected Option
Enter voice/data pair
Prompt
7108
Extension entered
Delete
Backspace
Exit Enter
System Programming: > System Programming:
Make a Selection Make a Selection
System Extensions Labeling Language
SysRenumber Options Data
Operator Tables Print
LinesTrunks AuxEquip Cntr-Prg
Exit NightSrvce Exit
