MERLIN LEGEND Communications System Release 5.0
System Manager’s Guide
555-650-118
Issue 1
June 1997
Managing the System
Page 6-67
Connecting Auxiliary Equipment
6
For Voice Messaging System and Automated Attendant
The number of rings cannot be programmed for individual voice messaging
systems; the single setting applies for all. Use the Group Type procedure in
“Optional Group Features” (Chapter 3,
System Programming) to assign VMI ports
as either integrated or generic.
Valid Entries
Touch-tone duration: 50 to 200 ms, in increments of 25 ms
Interval between digits: 50 to 200 ms, in increments of 25 ms
Number of rings before transfer: 0 to 9
Task List: Connecting Auxiliary Equipment
6
o
Obtain Form 2c, System Numbering: Line/Trunk Jacks, and the
appropriate individual telephone form (4d, 4e, 4f, 5b, or 5c). For a voice
messaging system or auto attendant system, see the forms packaged with
the application.
o
If necessary, read “Auxiliary Equipment” in
System Programming, Chapter
4, for additional information.
o
Plan changes using the planning guidelines above; record the new values
on the form(s).
o
Open the System Programming menu from the console or a PC with SPM.
o
Program the change(s), following the appropriate instructions for “Auxiliary
Equipment” in
System Programming, Chapter 4, or the appropriate
summary programming instructions below.
NOTE:
For Music On Hold and maintenance alarms, System Idle is
required; for loudspeaker paging, Line/Trunk Idle is required.
o
When you have finished, file the form(s) with the rest of the planning forms.
Programming Instructions
6
For fax machines:
Console Procedure
AuxEquip
→
Fax
→
Extension
→
Dial ext.
no.
→
Enter
→
Exit
→
Msg Waiting
→
Dial fax machine
ext. no.
→
Enter
→
Dial message waiting indicator ext.
no.
→
Enter
→
Threshold
→
Drop
→
Dial no. of
seconds
→
Enter
→
Exit
→
Exit
PC Procedure
%
→
→
→
Type ext. no.
→
→
!
→
→
Type fax machine ext. no.
→
→
Type message
waiting indicator ext. no.
→
→
→
3
+
0
→
Type
no. of seconds
→
→
!
→
!
