MERLIN LEGEND Communications System Release 5.0
System Manager’s Guide
555-650-118
Issue 1
June 1997
About the System
Page 2-11 System Overview
2
Figure 2–5. System Overview
Telephone
Company
MERLIN
LEGEND
Auxiliary
Components
Telephones
and Other
Equipment
MERLIN
LEGEND
Communications
System
Control Unit
Applications
Telephone Company
Central Office
(CO)
Incoming Trunks
CAUTION POWER
ON OFF
AG INPUT
FR
GND
Turn of f power bef ore inser ting or remo ving modules
408 GS/LS 44GS or LS Outside Lines/ 8 Analog
T elephones
(A TL)
408 008 M LX 8 M LX (D igital) T e lephones
012
PR OCESSOR
