Parts Catalog

7-7

4227-X00

Asm-
Index

Part

Number

Description

3 -1

11A6229

Sensor, Auto Gap

2

11A6216

Board and Bracket, Sub Logic (4227-100)

2

12G0214

Board and Bracket, Sub Logic (4227-200)

3

11A6255

Screw, Parts Packet

4

11A6215

Motor, Paper Feed Assembly, with Bracket

5

11A6257

Bearing, Parts Packet

6

11A6256

Gears, Parts Packet (4227-100)

6

12G0212

Gears, Parts Packet (4227-200)

7

11A6220

Motor, Ribbon Drive and Gear Plate Assembly

9

11A6221

Plate Assembly, Belt Tension Pulley

10

11A6227

Motor, Auto Gap (4227-100)

10

12G0220

Motor, Auto Gap (4227-200)

11

79F4832

Roller, Lower Pinch

12

11A6258

Spring, Parts Packet

13

11A6226

Bracket, Carrier Motor (4227-100)

13

12G0230

Bracket, Carrier Motor (4227-200)

14

11A6225

Motor, Carrier Assembly (4227-100)

14

12G0231

Motor, Carrier Assembly (4227-200)

15

11A6219

Cable, Printhead and Retainer (4227-100)

15

12G0225

Cable, Printhead and Retainer (4227-200)

16

11A3310

Cam, Release Slider

17

11A3311

Cam, Sub Slider

18

11A6218

Printhead (4227-100)

18

12G0224

Printhead (4227-200)

19

11A6224

Roller and Spring, Carrier

20

11A6222

Carrier Asm. with Belt & Oil Felt (4227-100)

20

12G0232

Carrier Asm. with Belt & Head Cooling Gum (4227-200)

21

11A6223

Shaft, Carrier

22

11A6228

Lever, Paper Select

23

11A6214

Gear Plate, Right

24

11A6217

Cable, Sub Logic Board (4227-100)

24

12G0215

Cable, Sub Logic Board (4227-200)

25

12G0210

Main Logic Card Dust Cover

NS

11A6202

Gear Cover, Left
