Lexmark 4227-X00 - Manual (Page 132)

Parts Catalog 7-5
4227-X00
Asm-
Index Part
Number
Description
2 -1 11A6231 Feed Roller, Upper
2 11A6257 Bearing Kit
3 11A6233 Frame Support Shaft
4 11A6240 TOF & Paper Empty Sensors with Flags & Springs
5 11A6239 Paper Guide / Platen Assembly
6 11A6234 Bracket, Auto-Gap Motor (4227-100)
6 12G0229 Bracket, Auto-Gap Motor (4227-200)
7 11A6241 Roller, Feed (Lower)
8 79F4832 Roller, Pinch (Lower)
9 11A6235 Side Frame Assembly, (Left) (4227-100)
9 12G0221 Side Frame Assembly, (Left) (4227-200)
10 11A6237 Sensor, Paper Select
11 11A6256 Gear Kit
12 11A6232 Separator, Paper
13 11A6236 Latch, Ribbon
14 11A6238 Side Frame Assembly, (Right)
15 11A6255 Screw and Clip Kit
16 11A6258 Spring Kit
17 11A6230 Plate, Carrier
18 11A6209 Tractor Side Frame, (Left)
19 11A6210 Tractor Side Frame, (Right)
20 11A6256 Gear Kit
21 11A6211 Tractor Pair, with Sensors (Left and Right)
22 11A6212 Shaft Kit, Tractor
23 79F4830 Paper Guide, Tractor
24 12G0228 Carrier Motor Cooling Fan (4227-200)
