Lexmark 4227-X00 User Manual
Page 114

Connector Locations
5-11
4227-X00
Main Logic Board<-->Sub Logic Board (4227-100)
Main Logic Board
CN3
Sub Logic Board
CN2
Pin 1
HDTHERMO
Pin 2
R7COM
Pin 3
L4COM
Pin 4
L1COM
Pin 5
L8COM
Pin 6
L5COM
Pin 7
R1COM
Pin 8
R4COM
Pin 9
R3COM
Pin 10
R8COM
Pin 11
R6COM
Pin 12
R9COM
Pin 13
R2COM
Pin 14
R5COM
Pin 15
L9COM
Pin 16
L6COM
Pin 17
L7COM
Pin 18
L2COM
Pin 19
L3COM
Pin 20
R9
Pin 21
R3
Pin 22
R5
Pin 23
R1
Pin 24
L6
Pin 25
L8
Pin 26
L2
Pin 27
L4
Pin 28
L1
Pin 29
L3
Pin 30
L5
Pin 31
L7
Pin 32
R8
Pin 33
L9
Pin 34
R4
Pin 35
R6
Pin 36
R7
Pin 37
R2
Pin 38
NC
Pin 38
HDTHERMO
Pin 37
R7COM
Pin 36
L4COM
Pin 35
L1COM
Pin 34
L8COM
Pin 33
L5COM
Pin 32
R1COM
Pin 31
R4COM
Pin 30
R3COM
Pin 29
R8COM
Pin 28
R6COM
Pin 27
R9COM
Pin 26
R2COM
Pin 25
R5COM
Pin 24
L9COM
Pin 23
L6COM
Pin 22
L7COM
Pin 21
L2COM
Pin 20
L3COM
Pin 19
R9
Pin 18
R3
Pin 17
R5
Pin 16
R1
Pin 15
L6
Pin 14
L8
Pin 13
L2
Pin 12
L4
Pin 11
L1
Pin 10
L3
Pin 9
L5
Pin 8
L7
Pin 7
R8
Pin 6
L9
Pin 5
R4
Pin 4
R6
Pin 3
R7
Pin 2
R2
Pin 1
NC
