11 I/O Por ts
11.1 Description
The MN102H75K/85K contains 50 pins that form general-purpose I/O ports.
Ports 0, 1, 2, 3, 4, and 5 are 8-bit ports, and port 6 is a 2-bit port. All of these pins
have alternate functions. (Ports 7 and 8 are only available with the quad flat
package.)
Table 11-1 I/O Port Pins
Port
Associated Pins
Port 0
P07– P00
Port 1
P17– P10
Port 2
P27– P20
Port 3
P37– P30
Port 4
P47– P40
Port 5
P57– P50
Port 6
P61– P60
Port 7
P77– P70
Port 8
P87– P80
