7.10.3 Display Sizes
■
Graphic tile sizes
The settings shown are for interlaced displays. In progressive displays, the vertical size settings (GVSZ[1:0]) are as follows:
01 = 1x, 10 = 2x, and 11 = 3x. The 00 setting is reserved.
Figure 7-27 Graphic Tile Size Combinations
b'00'
b'01'
b'10'
b'11'
b'00'
b'01'
b'10'
b'11'
Ч
1
Ч
2
Ч
3
Ч
4
Ч
1
Ч
2
Ч
6
Ч
4
GVSZ[1:0]
GHSZ[1:0]
16
32
48
64
16
32
64
96
